Nice Smart-Control
Product number:
301617040301
Manufacturer:
Nice
EAN:
5902701703417
Product information "Nice Smart-Control "
The Nice Smart-Control extends the functionality of classic devices and wired sensors. These devices can be integrated into the Z-Wave network with the Smart-Control.
This product is intended for connection to FIBARO gateways, including the Home Center 3 and Home Center 3 Lite. The device communicates via Z-Wave. The device can be operated and automated via the Z-Wave network.
Features
- Integrated temperature sensor
- Connect with up to six DS18B20 (temperature) sensors, one DHT (humidity and temperature) sensor, two-wire analog sensors, three-wire analog sensors and two binary sensors.
Properties "Nice Smart-Control "
| Communicatie & Protocol: | Z-Wave |
|---|---|
| Dimensions Product: | 29 x 18 x 13 mm |
| In accordance with guidelines: | RED 2014/53/EU RoHS 2011/65/EU |
| Inputs: | 2 0-10V or digital inputs 1 serial 1-wire input |
| Installation method: | Flush mount |
| Maximum load capacity: | 150mA |
| Outputs: | 2 potential-free outputs |
| Output voltage: | 30V DC / 20V AC ±5% |
| Power source: | 9-30V DC ±10% |
| Protocol: | Z-Wave |
| Supported digital sensors: | 6x DS18B20 or 1x DHT22 |
| Transmit power: | +7 dBm |
Data according to manufacturer. Errors and changes reserved.
Downloads "Nice Smart-Control "
Compatibility
| Controller | Controller FW | Device FW | Compatibility Status | Note |
|---|---|---|---|---|
| FIBARO Home Center 3 | 5.110 | Compatible | ||
| FIBARO Home Center 3 Lite | 5.110 | Compatible |
