FIBARO Roller Shutter 4
Control electric motors for roller shutters, blinds, garages and gates. Controlled by precise positioning and support for energy measurement.
Product number:
301620030301
Manufacturer:
Nice
Product information "FIBARO Roller Shutter 4"
The Nice Roll-Control 2 is designed for controlling and precisely positioning AC-powered motors, including roller shutters, blinds, awnings, screens and gates. The Roll-Control 2 is equipped with a Z-Wave 800 chip. This makes the module much more energy-efficient in standby mode and provides a longer range, resulting in a more stable mesh network.
The module supports motors without a built-in driver but with mechanical or electronic limit settings. This is the main difference compared to the Nice Roll-Control.
Nice has developed a new inclusion procedure for integration with the Home Center 3, allowing you to select the correct settings right away.
Features
- Z-Wave 800
- Compatible with AC motors with electronic or mechanical limit settings
- Measures active energy consumption
- Works with various types of switches, including push-buttons and toggle switches
- Supports motors for opening, closing and tilting
- Not compatible with motors with a built-in driver
Properties
| Actors: | Roller shutter and curtain control |
|---|---|
| Battery included: | Yes |
| Built-in box: | Ø = 50mm, depth ≥ 60mm |
| Communicatie & Protocol: | Z-Wave |
| In accordance with guidelines: | RED 2014/53/EU RoHS 2011/65/EU |
| Installation method: | Flush mount |
| Maximum load capacity: | 4.2A - resistive voltage 1.7A - inductive voltage |
| Operating humidity: | 10-95% relative humidity without condensation |
| Operating temperature: | 0–35°C |
| Power source: | 110-240V AC, 50/60Hz |
| Protocol: | Z-Wave 800 |
| Radio frequency: | 868.0–868.6MHz 869.7–870.0MHz |
| Range: | outdoor up to 50m indoors up to 40m (Depending on terrain and building construction) |
| Supported load types: | Resistive Single phase AC motor |
| Transmit power: | +6 dBm |
Downloads "FIBARO Roller Shutter 4"
